OMNISIL WOVEN CLOTHS



  • Furnace Curtains

  • Stress Relieving Insulation

  • Filtration Turbine Covers

  • Welding & Burning Blankets

  • Cable Tray Insulation

  • Steam Pipe Lagging



OmniSil woven cloths are a new generation of continuous filament amorphous silica materials available in several thicknesses and weights.

The intended use for these products are in all high temperature applications where the need for thermal insulation and/or protection is required.

The OmniSil cloths are hygienically safe and provide a viable alternative to asbestos, fiberglass. refractory ceramic fibers and the other contemporary silica products where safety, performance and cost effectiveness are the key issues.

All the OmniSil cloths can be coated with a variety of elastomer coatings to improve surface abrasion and toughness. The fabrics can also be aluminized for increased radiant heat reflectivity and can be cut, sewn and custom fabricated to specific customer requirements.



Characteristic

Units

OS-M60

OS-300

OS-600

OS-1000



Silica Content

%

94.0

94.0

94.0

94.0

Aluminum Content

%

4.0

4.0

4.0

4.0

Sodium Content

%

0.8

0.8

0.8

0.8

Total Halogens

ppm

Nil

Nil

Nil

Nil













Weave

-

Mesh - 060" Cell

Plain

8-H satin

12-H satin

Filament Diameter

Micron

6.0

6.0

6.0

6.0

Thickness

Inch

.030

.020

.030

.050

Weight

Oz/yd 2

16.0

10.0

18.0

36.0

Width

Inch

35.0

34.0

35.0

35.0

Length

Yards

50.0

50.0

50.0

50.0

Break Strength (W)

Lbs/In

-

140.0

400.0

480.0

Break Strength (F)

Lbs/In

-

140.0

240.0

330.0













Steady Use Temp

°F

>1800

>1800

>1800

>1800

Melt Temp

°F

>3000

>3000

>3000

>3000

Lineal Shrinkage

%

5.0

<0.3

5.0

5.0
